Engine

• 20 HP Honda GX630 Premium
• Electric start with 18 amps/200Watts
• Gasoline, air cooled, 4 stroke, one cylinder, OHC
• 3 years Warranty by Honda

Saw head

• Maximum diameter of log 32 inches
• Maximum width of planks 23 inches
• 7/8 inch last board cut capability
• Blade of 162 x 1 1/4 APEX RF (1 blade included)
• Single, one piece solid front panel, for easy access blade maintenance
• Electric saw head positioning and auto-lock electric winch of 4000 lbs mounted on a drum shaft with double cables of aeronautical quality​​
• High grade double bearing blade-guide, Zinc design and adapted for heavy usage with a 18 inch wheel
• MXV-890 Drive Belt
• B56 Flywheel Belt
• Large 7 gallons (26 liters) removable lubrification tank
• Heavy-Duty frame construction, completely made of 2’’X2’’ solid welds
• Large colored graduated ruler, details from ¾ up to 4 Inches,
• Simple cam lock blade tensioning for fast and easy adjustment
• Hydraulic blade tensionner available in option – contact your dealer for more information
•
• Auto-blade lube system automatically turns on and off fluid flow during operation
• Automatic Blade-Brake system , maximize speed and the lifespan of your blades
• Automatic engine throttle and saw Blade engagement.

Base

• 21 feet maximum board length, onto a 24 foot bed
• Extra solid steel tubing frame 2X6 3/16, completely welded with crosspieces, no joints
• 8 conveyor rollers of 12 inches monted on bearing coated with zinc plating
• 4 log clamp, simple one hand cam-lock design
• 4 integrated levelers with casters, allow to compensate the taper of a log and rotate it without effort
• 4 adjustable jacks and 5 stabilizing legs for maximum stability
