4WD (FRONT WHEEL MECHANICAL ASSIST)
Go from 2WD to a 4WD with a simple move of a lever.
4WD (FRONT WHEEL MECHANICAL ASSIST)
Go from 2WD to a 4WD with a simple move of a lever.
INDEPENDENT PTO
Easiest PTO to operate that can be turned on or off with a switch.
DUAL PEDAL, 3 RANGE HST
Easier and more comfortable than rocker pedals.
STANDARD 12X12 SYNCHRO SHUTTLE
Makes changing direction easier than competitive non-shuttle gear models. 12 forward / 12 reverse gear transmission provides more operating speeds than others in its class for superior control, precision and safe operations for virtually any application.
SIDE MOUNTED MAIN GEAR LEVER
Maximizes space and makes getting on and off tractor easier than straddle type like other brands.
STANDARD HYDROSTATIC POWER STEERING
Make your turning easier — improve control and reduce fatigue.
STANDARD FOLDABLE ROPS
Allows storage in low clearance buildings or sheds.
YOUR CHOICE OF TIRES AT NO ADDITIONAL COST*
Choose Ag, Industrial or Turf tires at no additional cost. * Subject to dealer inventory.
4WD (FRONT WHEEL MECHANICAL ASSIST)
Go from 2WD to a 4WD with a simple move of a lever.
3-POINT HITCH
Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
ERGONOMICALLY DESIGNED 3-POINT HITCH CONTROLS
Easily accessible for maximum comfort and convenience with hydraulic position control.
STANDARD DRAW BAR
Increases the usefulness of the tractor without the additional optional cost.
LARGE FUEL TANK
7.4 gallon capacity provides long operation times between fill ups.
STANDARD RUBBER MAT
Reduces noise, vibration and prevents slipping.
MITSUBISHI TIER 4 ENGINE
Fuel efficient engine delivers reliable performance. Rubber engine mounts reduce operator platform vibration. Standard preheat starting aid improves cold weather starting.
LS CRDI TIER 4 ENGINE
Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather. Includes engine speed cruise control.
EASY OPEN ONE-PIECE STEEL HOODProvides accessibility for easy maintenance.
MODERN ERGONOMIC DESIGN
This compact is ergonomically designed .
ADJUSTABLE SEAT WITH SEAT BELT
Keeps you in a comfortable and safe position for maximum control.
ENGINE
Type: 3 Cylinder, liquid-cooled, Diesel, NA, IDI
Model (Tier 4): Mitsubishi S3L2
Engine HP (Gross): 24.6
PTO HP: 19.2
Rated Speed (RPM): 2,500
Displacement (cu. in.): 80.4
Fuel Tank Capacity (gal): 7.4
Alternator (V-A): 12 – 50
DRIVE TRAIN
Transmission: Synchro shuttle
No. of Speeds: F12 x R12
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear (rpm): Standard (540)
HYDRAULIC SYSTEM
Control System: Position
Implement pump (gpm): 7.9
Steering pump (gpm): 4.6
Total flow (gpm): 12.5
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,808
Remote Valves: Option
DIMENSIONS
Overall length, Frame to link, (in.): 118
Wheelbase (in.): 66
Overall width with tires, in. (in.): 54
Height to top of ROPS (in.): 88
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20
WEIGHT
Total weight without ballast (lbs.): 2,434
ENGINE
Type: 3-cylinder, CRDI, liquid-cooled, Diesel, NA
Model (Tier 4): L3C19-D2
Engine HP (Gross): 35
PTO HP: 29.7
Rated Speed (RPM): 2,600
Displacement (cu. in.): 114.7
Fuel Tank Capacity (gal): 7.4
Alternator (A-V): 12V – 70
DRIVE TRAIN
Transmission: Syncro Shuttle
No. of Speeds: F12 x R12
Brakes: Wet, Multi-Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear, rpm: 540 (Standard)
Mild, rpm: 2,000 (Option)
HYDRAULIC SYSTEM
Control System: Position
Implement pump (gpm): 8.2
Steering pump, gpm: 4.1
Total flow (gpm): 12.3
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,808
Remote Valves: Option
DIMENSIONS
Overall length, Frame to link (in.): 121
Wheelbase (in.): 69
Overall width tires (in.): 54
Height to top of ROPS (in.): 88
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20
WEIGHT
Total weight without ballast (lbs.): 2,866
ENGINE
Type: 3-Cylinder, CRDI, Water-cooled, Diesel, TC
Model: L3C19-T
Engine HP (Gross): 40
PTO HP: 34.0
Rated Speed (RPM): 2,600
Displacement (cu. in.): 114.7
Fuel Tank Capacity (gal): 7.4
Alternator (V-A): 12-70
DRIVE TRAIN
Transmission: Synchro Shuttle
No. of Speeds: F12 x R12
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear, rpm: 540 (Standard)
Mid., rpm: 2000 (Option)
HYDRAULIC SYSTEM
Implement pump (gpm): 8.2
Steering pump (gpm): 5.5
Total flow (gpm): 13.7
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,808
Remote Valves: Option
DIMENSIONS
Overall length Frame to link (in.): 121
Wheelbase (in.): 69
Overall width with tires (in.): 54
Height to top of ROPS with (in.): 88
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20
WEIGHT
Total weight without ballast (lbs.): 2,881
ENGINE
Type: 3 Cylinder, liquid-cooled, Diesel, NA, IDI
Model (Tier 4): S3L2
Engine HP (Gross): 24.6
PTO HP: 17.2
Rated Speed (RPM): 2,500
Displacement (cu. in.): 80.4
Fuel Tank Capacity (gal): 7.4
Alternator (V-A): 12 – 50
DRIVE TRAIN
Transmission: HST
No. of Speeds: 3 Ranges
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear (rpm): Standard (540)
HYDRAULIC SYSTEM
Control System: Position
Implement pump (gpm): 7.9
Steering pump (gpm): 4.6
Total flow (gpm): 12.5
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,808
Remote Valves: Option
DIMENSIONS
Overall length, Frame to link, (in.): 118
Wheelbase (in.): 66
Overall width with tires, in. (in.): 54
Height to top of ROPS (in.): 88
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20
WEIGHT
Total weight without ballast (lbs.): 2,469
ENGINE
Type: 3-Cylinder, CRDI, Water-cooled, Diesel, NA
Model (Tier 4): L3C19-D2
Engine HP (Gross): 35
PTO HP: 28.0
Rated Speed (RPM): 2,600
Displacement (cu. in.): 114.7
Fuel Tank Capacity (gal): 7.4
Alternator(V-A): 12 – 70
DRIVE TRAIN
Transmission: HST
No. of Speeds: 3 Ranges
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear, rpm: 540 (Standard)
Mid., rpm: 2000 (Option)
HYDRAULIC SYSTEM
Control System: Position
Implement pump (gpm): 8.2
Steering pump (gpm): 5.5
Total flow gpm: 13.7
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1808
Remote Valves: Option
DIMENSIONS
Overall length with to link (in.): 121
Wheelbase (in.): 69
Min. overall width (in.): 54
Height to top of ROPS (in.): 88
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20
WEIGHT
Total weight without ballast (lbs.): 2,870
ENGINE
Type: 3-Cylinder, CRDI, Water-cooled, Diesel, TC
Model: L3C19-T
Engine HP (Gross): 40
PTO HP: 34.0
Rated Speed (RPM): 2,600
Displacement (cu. in.): 114.7
Fuel Tank Capacity (gal): 7.4
Alternator (V-A): 12-70
DRIVE TRAIN
Transmission: HST
No. of Speeds: 3 Ranges
Brakes: Wet, Multi-Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear, rpm: 540 (Standard)
Mid., rpm: 2000 (Option)
HYDRAULIC SYSTEM
Implement pump (gpm): 8.2
Steering pump (gpm): 5.5
Total flow (gpm): 13.7
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,808
Lift control type: Manual
DIMENSIONS
Overall length with to link (in.): 121
Wheelbase (in.): 69
Min. overall width with AG tires (in.): 54
Height to top of ROPS with Ag tires (in.): 88
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20
WEIGHT
Total weight without ballast (lbs.): 2,884
