TF-LCD INSTRUMENT PANEL
Providing various information such as regen time, oil change interval, etc.
TF-LCD INSTRUMENT PANEL
Providing various information such as regen time, oil change interval, etc.
UPGRADED CONTROLS
Upgraded handles, knobs, audio system, engine kill switch, and guide lamp.
E/G RPM INTERLOCKING SWITCH STANDARD
When working at low RPm, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/ lift.
Includes ON/OFF function, eliminating converns about unintentional malfunction.
STANDARD SET OF REMOTE VALVES
Adds functionality and improves ease of use by allowing attachment of hydraulically controlled implements without the high, additional costs like others in its class to add the remotes as options.
*Picture shown with optional second set
4WD (FRONT WHEEL MECHANICAL ASSIST)
Go from 2WD to a 4WD with a simple move of a lever.
INDEPENDENT PTO
Easiest PTO to operate that can be turned on or off with a switch.
DUAL PEDAL, 3 RANGE HST W/ LINKED PEDAL
Easier and more comfortable than rocker pedals. Standard linked pedal that raises (or lowers) the RPMS, with movement of the pedals (when turned on).
SIDE MOUNTED MAIN GEAR LEVER
Maximizes space and makes getting on and off tractor easier than straddle type like other brands.
STANDARD HYDROSTATIC POWER STEERING
Make your turning easier — improve control and reduce fatigue.
STANDARD FOLDABLE ROPS
Allows storage in low clearance buildings or sheds.
YOUR CHOICE OF TIRES AT NO ADDITIONAL COST*
Choose Ag, Industrial or Turf tires at no additional cost. * Subject to dealer inventory.
4WD (FRONT WHEEL MECHANICAL ASSIST)
Go from 2WD to a 4WD with a simple move of a lever.
3-POINT HITCH
Category 1 with a hitch lift capacity of 1,433 lbs. allows usage of a wide variety of implements.
EXTENDABLE LOWER LINKS
Allows easier attachment of a wide variety of Category 1 implements with a 1,433 lbs lift capacity.
ERGONOMICALLY DESIGNED 3-POINT HITCH CONTROLS
Easily accessible for maximum comfort and convenience with hydraulic position control.
STANDARD DRAW BAR
Increases the usefulness of the tractor without the additional optional cost.
LARGE FUEL TANK
10.6 gallon capacity provides long operation times between fill ups.
STANDARD RUBBER MAT
Reduces noise, vibration and prevents slipping.
3 CYLINDER YANMAR TIER 4 ENGINE
ON 32 HP Models* Fuel efficient engine delivers reliable performance. Rubber engine mounts reduce operator platform vibration. Standard preheat starting aid improves cold weather starting. Includes cruise control.
4 CYLINDER YANMAR TIER 4 ENGINE
ON 42 HP Models* Fuel efficient engine delivers reliable performance. Rubber engine mounts reduce operator platform vibration. Standard preheat starting aid improves cold weather starting. Includes cruise control.
EASY OPEN ONE-PIECE STEEL HOODProvides accessibility for easy maintenance.
MODERN ERGONOMIC DESIGN
This compact is ergonomically designed .
ADJUSTABLE SEAT WITH SEAT BELT
Keeps you in a comfortable and safe position for maximum control.
ENGINE
Type: 3-Cylinder, CRDI, Water-cooled, Diesel, TC
Model: Yanmar 4TNV88C-MLST
Engine HP (Gross): 42.5
PTO HP: 35.4
Rated Speed (RPM): 2,600
Displacement (cu. in.): 133.6
Fuel Tank Capacity (gal): 10.6
Alternator (V-A): 12-55 Amps
DRIVE TRAIN
Transmission: Synchro Shuttle
No. of Speeds: F12 x R12
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear, rpm: 540 (Standard)
Mid., rpm: 2000 (Option)
HYDRAULIC SYSTEM
Implement pump (gpm): 7.4
Steering pump (gpm): 5
Total flow (gpm): 12.4
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,433
Remote Valves: Option
DIMENSIONS
Overall length Frame to link (in.): 125
Wheelbase (in.): 74
Overall width with tires (in.): 66
Height to top of ROPS with (in.): 95
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 27 x 8.5 – 43X16-20
Turf Front / Rear 25 x 8.5 – 41X14-20
WEIGHT
Total weight without ballast (lbs.): 3,250
Model: L3003
Maximum Lift Height, in: 94.3
Bucket, in: 66
Clearance with Attachment Dump, in: 67
Reach at Maximum Height, in: 14.4
Maximum Dump Angle, deg: 48
Maximum Rollback Angle, deg: 42.5
Digging Depth, in: 4.8
Overall Height in Carry Position, in: 51.2
Lift Capacity (Bucket Pivot Pin, MAX, Height) lb: 2,063
Lift Capacity (Pivot pin @ 1.5m) lbs: 2,506
Breakout Force (A Pivot Pin), lbs: 3,723
Approx Weight (Loader w/o Bucket), lbs: 741
ENGINE
Type: 4-Cylinder, CRDI, Water-cooled, Diesel, TC
Model: Yanmar 4TNV88C-MLST
Engine HP (Gross): 42.5
PTO HP: 35.4
Rated Speed (RPM): 2,600
Displacement (cu. in.): 133.6
Fuel Tank Capacity (gal): 10.6
Alternator (V-A): 12-55 Amps
DRIVE TRAIN
Transmission: HST
No. of Speeds: 3 Ranges
Brakes: Wet, Multi-Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear, rpm: 540 (Standard)
Mid., rpm: 2000 (Option)
HYDRAULIC SYSTEM
Implement pump (gpm): 6.7
Steering pump (gpm): 5
Total flow (gpm): 11.7
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,433
Lift control type: Manual
DIMENSIONS
Overall length with to link (in.): 125
Wheelbase (in.): 74
Overall width (in.): 66
Height to top of ROPS with Ag tires (in.): 95
TIRE SIZE
Ag Front/Rear: 7 – 14 / 11.2 – 24
IND Front / Rear 27 x 8.5 – 43X16-20
Turf Front / Rear 25 x 8.5 – 41X14-20
WEIGHT
Total weight without ballast (lbs.): 3,294
