Large Capacity

Strong Clamping Power

Lever Quick Connect

Heavy Welded Construction
-
4' MCG1148A Specs
Attach Type: Dual type (Bobcat & Pin On)
Material: AR400
Weight (lb): 216
Overall width (in.): 49 3/4″
Rake width (in.): 48″
Closed height (in.): 27 5/8″
Jaw opening (in.): 30″
Side width (in.): 21″
Tooth thickness (in.): 0.24″
Number of teeth: 6 Bottom & 5 Top
Hydraulic cylinder: 2″ x 1 – 1/5″ Rod (4″ Stroke)
-
4 1/2' MCG1154A Specs
Attach Type: Bobcat type
Material: AR400
Weight (lb): 242
Overall width (in.): 56″
Rake width (in.): 54 3/8″
Closed height (in.): 27 5/8″
Jaw opening (in.): 30″
Side width (in.): 20 7/8″
Tooth thickness (in.): 0.24″
Number of teeth: 7 Bottom & 6 Top
Hydraulic cylinder: 2″ x 1 – 1/5″ Rod (4″ Stroke)
-
5' MCG3160A Specs
Attach Type: Bobcat type
Material: AR400
Weight (lb): 300
Overall width (in.): 62″
Rake width (in.): 60 1/4″
Closed height (in.): 31 1/2″
Jaw opening (in.): 41″
Side width (in.): 23 1/2″
Tooth thickness (in.): 0.24″
Number of teeth: 7 Bottom & 6 Top
Hydraulic cylinder: 2″ x 1 – 1/5″ Rod (6″ Stroke)
-
6' MCG3172A Specs
Attach Type: Bobcat type
Material: AR400
Weight (lb): 490
Overall width (in.): 76 3/4″
Rake width (in.): 75″
Closed height (in.): 31 1/2″
Jaw opening (in.): 41″
Side width (in.): 21 1/2″
Tooth thickness (in.): All outside teeth are 0.47″ thick. All teeth between outside teeth are 0.39″ thick
Number of teeth: 12 Bottom & 11 Top
Hydraulic cylinder: 2″ x 1 – 1/5″ Rod (6″ Stroke)
