ENGINE

Type: 3Cylinder-IDI

Model (Tier 4): 3TNV80F-ZXKLST(YANMAR)

Engine HP (Gross): 25

PTO HP: 19.3

Rated Speed (RPM): 2,800

Displacement (cu. in.): 77.3

Fuel Tank Capacity (gal): 6.79

Alternator (V-A): 12-40

DRIVE TRAIN

Transmission: HST

No. of Speeds: 3 Ranges

Brakes: Wet, Multi Disc

Steering: Hydrostatic Power Steering

PTO

Type: Independent

Rear (rpm): 540

Mid PTO (option): 2,500

HYDRAULIC SYSTEM

Control System: Position

Implement pump (gpm): 5.6

Steering pump (gpm): 3.7

Total flow (gpm): 9.3

Category, 3 pt hitch: CAT 1

Hitch Lift capacity (lb): 1,896

Remote Valves: 1 PAIR (Option)

DIMENSIONS

Overall length, Frame to link, (in.): 111.9

Wheelbase (in.): 63.4

Overall width with tires, in. (in.): 48.7

Height to top of ROPS (in.): 86.4

TIRE SIZE

IND (Front/Rear): 23 x 8.5 – 12 / 12 – 16.5

Turf (Front/Rear): 22 x 8.5 – 12 / 31 x 15.5 – 15

WEIGHT

Total weight without ballast (lbs.): 1,764

LL2300 – FRONT END LOADER

Bucket (in): 54.3

Maximum Lift height (in): 84.4

Clearance with Attachment Dump (in): 59.1

Reach at Maximum Height (in): 17.9

Maximum Dump Angle (deg): 55

Maximum Rollback Angle (deg): 40

Digging Depth (in): 4.5

Overall Height in Carry Position (in): 46

Lift Capacity (@ Pivot pin) (lbs): 1,067

Breakout Force (@ Pivot pin) (lbs): 2,290

Approx. Weight (Loader w/o Bucket) (lbs): TBD
